The CV4104 (commercially the M8163) is a special quality voltage stabiliser.The tube strikes at 180 Volts and regulates at 150 Volts. For output currents of between 5 mA and 15 mA the voltage regulation is 5 Volts.
The Mullard logo and M8163 showing complete equivalence between the two designations.The thin glass tube envelope is 18 mm in diameter and, excluding the B7G base pins, is 45 mm tall.Reference: 1040. Type CV4104 was first introduced in 1960. See also 1960 adverts. |
