9006

Sensibly equivalent to:
CV2769
See also:
Acorn Antiques

Extras ▼



The 9006 miniature valve is a general purpose UHF diode.
The thin glass tube envelope is 17 mm in diameter and, excluding the B7G base pins, is 38 mm tall.
Reference: Datasheet. Type 9006 was first introduced in 1943.



Absolute Maximum Operating Conditions
Diode
Vh
Ah
Va
mAa
6.3
0.15
270
5.0
Thanks to Frank Philipse for supplying the above PDF datasheet.
